Garage door tracks have a major impact on the operation and safety of your garage door system. While typical traditional garage doors are generally mounted on vertical tracks, horizontal garage door tracks may suit properly garage designs.
How To make Perpendicular Garage Door Horizontal Tracks: A How To Guide
This article will guide you through the process of converting perpendicular garage door tracks to horizontal ones, providing you with valuable insights and step-by-step instructions on how to hide garage door tracks and address concerns like garage door track not level.
Understanding Garage Door Track Systems
Before converting, you must first have a clear understanding of the main components that comprise a garage door track system, including:
- Vertically running tracks: Installed on the sides of the garage door opening.
- Horizontally running tracks: Extend into the garage ceiling when the door is open, ensuring stability.
- Curved tracks: Attach vertical and horizontal tracks to allow the door to follow the proper route.
- Rollers: Ensure smooth door movement along the tracks.
If you’re considering how to hide garage door tracks from inside or transitioning to a more efficient layout, understanding these components is key.
Benefits of Horizontal Tracks
Conversion of vertical to horizontal tracks has the following advantages:
- Storage Efficiency: Horizontal tracks let the door hang directly under the ceiling, maximizing vertical space.
- Safety: Properly aligned horizontal tracks evenly distribute the door’s weight, minimizing stress on the opener.
- Enhanced Aesthetics: A horizontal garage door layout creates a neater, more streamlined look inside the garage.
Preparing for the Conversion
Tools and Materials Needed
To convert your garage door tracks, you will need:
- Horizontal track kit (matched to the size and weight of your door)
- Tape measure and level (to ensure the garage door track is level)
- Drill and drill bits
- Socket wrench set
- Safety glasses and work gloves
Safety Considerations
Your safety should always be the first concern when working on garage doors. You must always:
- Disconnect the garage door opener before starting.
- Use proper lifting techniques for heavy components.
- Wear protective gear like gloves and glasses.
Step-by-Step Conversion Process
1. Measure and Plan
First, measure your garage to ensure horizontal tracks fit properly. Be sure to:
- Verify clearance above the door opening (12-14 inches is standard).
- Confirm your garage has sufficient depth for the tracks (door height + 18 inches).
This planning helps avoid issues such as garage door geometry misalignment or improper track installation.
2. Remove the Old Tracks
Carefully take off the vertical tracks:
- Disconnect vertical tracks from the jamb brackets.
- Remove screws securing the tracks to the wall.
- Ensure the door is supported during removal.
3. Install the New Horizontal Tracks
To install horizontal tracks:
- Attach curved sections to the existing vertical tracks.
- Use hanging brackets to secure the horizontal tracks to the ceiling.
- Use a level to align and position the tracks correctly.
4. Adjust the Spring Tension
Adjust the springs to accommodate the new tracks:
- For torsion springs, turn the winding cones to increase or decrease tension.
- For extension springs, move the S-hooks to balance tension.
Caution: Improper handling of springs can be dangerous. If unsure, consult a professional.
5. Test and Fine-tune
After installation:
- Check the door’s smooth movement.
- Verify no strange noises or resistance.
- Ensure the door stays balanced when partially open.
Common Challenges and Solutions
- Garage Door Track Not Level: Use shims or adjustable brackets to correct alignment.
- Insufficient Headroom: Consider low-headroom kits, which require as little as 9 inches of clearance.
- Door Balance Issues: Recheck and adjust spring tension if the door is unbalanced.
Maintenance Tips for Horizontal Tracks
Keep your tracks in excellent condition with these tips:
- Inspect all components regularly for wear or damage.
- Lubricate rollers and hinges with silicone-based lubricant every six months.
- Ensure tracks are free of debris and tighten any loose bolts.
When to Seek Professional Help
Seek assistance if:
- You’re unfamiliar with leveling a garage door opener or working with springs.
- Structural adjustments are required for the new tracks.
- You’re installing a trackless garage door or need advanced customization.
Conclusion
By converting perpendicular tracks to horizontal ones, you can optimize functionality and aesthetics in your garage.
We hope this guide help you complete the project while addressing common concerns like garage door track not level or how to make perpendicular garage door horizontal tracks without major adjustments. Properly installed horizontal tracks can provide years of reliable service and improve your garage’s usability.
